DJI Mavic 3 Thermal
- 640*[email protected] Thermal camera
- Up to 56 x hybrid zoom
- RTK Module /Speaker
- The New Entry Level Thermal Drone
30-03-2023
30-03-2023
30-03-2023
30-03-2023
29-03-2023
29-03-2023
29-03-2023
29-03-2023
DJI Mavic 3 Thermal
The swiftly deployed Mavic 3T features excellent imaging capabilities and an increased 45-minute flight time, making it particularly well suited for inspection and emergency services missions. This adaptable drone provides high-resolution thermal imaging as well as visual data collecting, including hybrid zooming. Integrate with a variety of accessories to optimise operations, such as a high-volume loudspeaker that is ideal for public safety and search and rescue missions, and an RTK Module for improved georeferencing accuracy.
1 x Mavic 3 Thermal
1 x DJI RC Pro Enterprise
1 x Mavic 3 Battery
1 x Carrying Case
3 x Propeller (pairs)
1 x SD card
1 x Gimbal cover x 1
1 x Standard charger (100W)
1 x Power Cable
1 x USB-C Cable
1x USB-C to USB-C Cable
-
640*[email protected] Thermal camera
-
Up to 56 x hybrid zoom
-
4/3" inch CMOS Wide Camera
-
45 Minutes Maximum Flight Time
-
Supports up to 28x synchronized zoom between thermal and visual cameras
Premium Camera Performance
Up to 28x synchronised zoom between thermal and visible cameras is supported by M3T. Both pictures can be scaled at once by users. This doubles efficiency and facilitates side-by-side comparison of details.
DJI Mavic 3 Thermal Camera Specifications
Wide Camera
- ½ inch CMOS, 48MP
- 24mm Equivalent Focal Length
Tele Camera
- ½ inch CMOS, 12MP
- 162mm Equivalent Focal Length
- Up to 56x hybrid zoom
Thermal Camera
- 640 x 512 @ 30Hz
- 40mm Equivalent Focal Length
- 61° Display Field of View (DFOV)
Game-Changing Transmission
Improved obstacle detecting, navigation, and transmission systems are all included in the Mavic 3 Thermal's upgraded safety features.
Take advantage of the greatest control range of 8 kilometres with the DJI O3 Enterprise Transmission. Operators can acquire a high frame rate live feed at 1080p/30fps and send signals with greater stability thanks to DJI O3 Enterprise Transmission.
Six omnidirectional fish-eye sensors support the new and upgraded DJI APAS system 5.0, which has zero blind areas for obstacle recognition.
DJI AirSense: Detects ADS-B signals from adjacent conventional aircraft to alert users to nearby air traffic and improve airspace awareness.
Advanced RTH: The drone finds the fastest and most efficient path back to its starting place autonomously.
Compact and Portable
Lightweight 915g/920g airframe. A compact body that fits in the palm of your hand Perfect for beginner and veteran operators alike.
Flagship Flight Safety
- Wide-angle lenses for omnidirectional obstacle sensing with zero blind spots
- Advanced RTH
- APAS 5.0 for automatic rerouting around obstacles
Full Software Suite
DJI Pilot 2
The RC has a built-in DJI Pilot 2 APP that supports multiple mission planning options, including waypoint, mapping, oblique and linear.
DJI FlightHub 2
Flight Hub 2 features are also available including live streaming, aircraft info, live 2D mapping, panorama and media upload, and mission planning.
DJI Terra
You can import images taken by M3E/M3T to Terra for 2D/3D reconstruction, M3T mapping is not recommended due to unreliable accuracy. Both M3E and M3T include one DJI Terra license for 3 months. The free license is activated when the drone is activated.
DJI Thermal Analysis Tool 3.0
DJI Thermal Analysis Tool 3.0 is supported at launch allowing you to create a report and manipulate the radiometric thermal data with the specific parameters following data capture.
