SkyRC D100neo AC/DC charger
SKU: SK-100199
- Parallel Charging
- USB C for charging
- Overload protection
SkyRC D100neo AC/DC charger
The SKY RC D100neo has two charging ports and can send 200W and 10A to each one. This means that two batteries can be charged at the same time. Because each cell of the balancer has 1000mA of current, the batteries are much more evenly balanced. The high-precision balancer also makes sure that the voltage compensation is done perfectly, with an accuracy of ±0.02V.
Size and Weight
Case Material: PC-ABS V0
Case Size: 116*110*79mm
Weight: 470g
Display
Display Type: TN
Size: 2.8 inch
Panel Active Area: 43.20*57.60mm
Resolution: 240x320 Pixel
Number of Colors: 262K
Power
DC Input Voltage: 10-30V
AC Input Voltage : 100-240V
Charger power:
AC: 100W MAX
DC: 200W MAX
Discharge power:
Main port: 5W
Balance port: 25W MAX (LiPo/6S)
20W USB-C Power Delivery:
QC3.0: 5V⎓3A, 9V⎓2A, 12V⎓1.5A 18W
PD: 5V⎓3A, 9V⎓2.2A, 12V⎓1.67A 20W
Battery
Battery Types/Cells:
LiPo/LiHV/LiFe/LiIon: 1-6cells
NiMH/NiCd: 1-15cells
Pb: 3S/6S/12S
Charge and Discharge
Charge current
LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.2-10.0A
Discharge current
LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.1-2.0A
Balance current
LiPo/LiFe/LiIon/LiHV：1.0A MAX
Operation
LiPo/LiFe/LiIon/LiHV: Balance CHG, Charge, Storage, Discharge
NiMH/NiCd: Charge, Re-Peak, CYCLE_C_D, CYCLE_D_C, Discharge
Pb: Normal, AGM Charge, Cold Charge, Discharge
