DJI Zenmuse H30T Drone Payload
- 48MP Wide camera
- 34x Optical/400x Digital Zoom Camera
- 1280 x 1024 Infrared Sensor
- Laser rangefinder with a 3,000m range
- Upgraded Thermal Sensor
- Improved Visual Zoom
SKU: CP.EN.00000529.01
Material Code: DJIEZENH30T
Brand: DJI
In Stock : Order within 22 hrs 15 mins for delivery by Tuesday, 10th December (UK Mainland)
Safe & Secure Checkout
DJI Zenmuse H30T Drone Payload
A flagship multi-sensor payload for the DJI M350 RTK/M300 RTK, the DJI Zenmuse H30T is appropriate for a variety of uses, such as inspection, security, and public safety.
Adaptable Payload
The H30T has a laser rangefinder with a 3,000-meter range, a 1280 x 1024 infrared sensor, a 48MP wide camera, a 34x optical/400x digital zoom camera, and an NIR auxiliary light. Both cameras support night scene mode.
Weatherproof
This sturdy payload can withstand temperatures ranging from -20° to 50°C and has an IP54 rating.
DJI Care Enterprise
For a price, DJI Care Enterprise (Basic) gives you the right to two replacements throughout the first year.
Zenmuse H30T x 1
Lens Cap x 1
microD Card (64GB) x 1
Storage Case x 1
Lens Cleaning Cloth x 1
Specification Value Zenmuse H30T Weight 920±5g Dimensions 170x145×165mm (L×W×H) Power 26 W Ingress Protection Rating IP54
*Under controlled laboratory conditions, it can achieve an IP54 protection rating by IEC60529 standards. The IP rating is not permanently effective and may decrease due to product wear and tear.Supported Aircraft Matrice 300 RTK (requires DJI RC Plus)
Matrice 350 RTKOperating Temperature -20° to 50° C (-4° to 122° F) Storage Temperature -20° to 60° C (-4° to 140° F) Gimbal Stabilisation System 3-axis (tilt, roll, pan) Angular Vibration Range Hover: ±0.002°
Flight: ±0.004°Mounting Detachable DJI SKYPORT Mechanical Range Tilt: -132.5° to +73°
Roll: ±60°
Pan: ±328°
(Structural limit, not controllable range)
Controllable Range Tilt: -120° to +60°
Pan: ±320°Operation Mode Follow/Free/Re-center Zoom Camera Sensor 1/1.8-inch CMOS, Effective Pixels: 40 MP Lens Actual Focal Length: 7.1-172 mm
(Equivalent focal length: 33.4-809.3 mm)
Aperture: f/1.6-f/5.2
DFOV: 66.7°-2.9°
Focus Mode MF, AFC, AFS Exposure Mode Manual, Auto Exposure Compensation ±3.0 (1/3 increments) Metering Mode Spot Metering, Average Metering AE Lock Supported Electronic Shutter Speed 1/8000-2 s ISO Range Single Shot: 100-25600
Night Scene: 100-819200Video Resolution Single Shot: 3840×2160@30fps, 1920×1080@30fps
Night Scene: 1920×1080@25fps, 1920×1080@15fps, 1920×1080@5fpsVideo Format MP4 Video Subtitles Supported Video Codec and Bit Rate Strategy H.264, H.265
CBR, VBRMaximum Photo Size 7328×5496, 3664×2748 Photo Format JPG Wide-Angle Camera Sensor 1/1.3-inch CMOS, Effective Pixels: 48 MP Lens Actual Focal Length: 6.72 mm (Equivalent focal length: 24 mm)
Aperture: f/1.7
DFOV: 82.1°Focus Mode MF, AFC, AFS Exposure Mode Manual, Auto Exposure Compensation ±3.0 (1/3 increments) Metering Mode Spot Metering, Average Metering AE Lock Supported Electronic Shutter Speed 1/8000-2 s ISO Range Single Shot: 100-25600
Night Scene: 100-409600
Video Resolution Single Shot: 3840×2160@30fps, 1920×1080@30fps
Night Scene: 1920×1080@25fps, 1920×1080@15fps, 1920×1080@5fps
Video Format MP4 Video Subtitles Supported Video Codec and Bit Rate Strategy H.264, H.265
CBR, VBRMaximum Photo Size 8064×6048, 4032×3024 Photo Format JPG Infrared Thermal Camera (H30T) Thermal Imager Uncooled VOx Microbolometer Lens Focal Length: 24 mm (equivalent focal length: 52 mm)
Aperture: f/0.95
DFOV: 45.2°Digital Zoom Equivalent 32× Video Resolution 1280×1024@30fps Video Format MP4 Maximum Photo Size 1280×1024 Photo Format JPG Measurement Accuracy ±2° C or ±2% (when the scene temperature is -20° to 150° C)
±5° C or ±5% (when the scene temperature is 150° to 550° C)Scene Range -40° to 550° C Spot Metering Supported Area Measurement Supported High Temperature Alarm Supported Isotherm Supported Colour Palettes Iron Red, Rainbow, White Hot, Black Hot, Green Hot, Fusion, Arctic Laser Rangefinder (H30T) Wavelength 905 nm Measurement Range 3-1200 m Measurement Accuracy ±1 m Laser Spot Size @100 m: approx. 50×450 mm
@1000 m: approx. 450×4500 mmSafety Regulation Level Class 1 Accessible Emission Limit (AEL) 260 nJ Reference Aperture 18 mm Max Laser Pulse Emission Power Within 5 Nanoseconds 52 W NIR Auxiliary Light Wavelength 850 nm FOV 4.6±0.6° (Round) Safety Regulation Level Class 1 Illumination Range @100 m: Approx. 8m diameter circle Special Features Hybrid Optical Zoom 34× Max Zoom 400× Link Zoom Supported Click to Aim Supported High-Res Grid Photo Supported Night Scene Supported Timestamp Supported Smart Capture Supported Video Pre-Recording Supported UHR Infrared Image Supported Data Storage Supported microSD Cards U3/Class10/V30 or above is required, or use a memory card from the recommended list. Supported File System exFAT Recommended microSD Cards
SanDisk Extreme Pro V30 A1 32GB microSDHC
Lexar 1066x V30 A2 64GB/128GB/256GB/512GB microSDXC
Kingston CANVAS GO! Plus V30 A2 64GB/128GB/256GB/512GB microSDXC
Zenmuse H30 supports the Security Code function. Go to Data and Privacy in DJI Pilot 2 and set the code to encrypt the microSD card installed on the camera. Download the DJI Decrypt Tool from the DJI official website to decrypt the microSD card on a Windows computer and access the card content.
Post-processing Software Mapping Software DJI Terra, DJI FlightHub 2 Post-processing Software DJI Thermal Analysis Tool 3
Improved Thermal Camera with Better Infrared Information 1280 × 1024 Resolution in Infrared: The 1280 x 1024 thermal camera is four times better than the H20T. It includes a digital zoom of 32x as well. At higher zoom levels, photos are guaranteed to stay clear thanks to the Ultra-High Resolution Infrared Image feature.
Three infrared gain options are supported by the H30T's new high-resolution mode. High-Res mode is best for watching objects with slight temperature variations, Low Gain mode allows for a greater temperature range, and High Gain mode offers accurate temperature readings.
Infrared and Visual Cameras Link Zoom, which scales the RGB and thermal images simultaneously to preserve the same viewpoint, is supported by both the zoom and thermal cameras.
Broad Temperature Range: Measure temperatures up to 1600°C (three times higher than the previous version) with the infrared density filter, which is sold separately.
Scene at Night
Improved Detail Clarity in Low-Light Conditions
NIR Auxillary Light: The auxiliary light improves illumination in the centre of the screen as the camera view changes to black and white.
Black and White Mode: Infrared light can be utilised to illuminate the scene below without making it too bright, and the landscape appears in black and white.
Full-Colour Mode: You can see a brighter landscape because the IR filter that would normally block out infrared light is gone.
Reduce background noise while filming with enhanced noise reduction.
Laser-Assisted Focussing: A laser rangefinder automatically helps with focussing.
Night Scene Mode: The laser spot can be seen in the middle of the black-and-white camera view when both Night Scene mode and IR Light are turned on.
H30T Visual And Zoom Cameras
34x optical and 400x digital zooms are supported by the 1/1.8-inch 40MP zoom camera.
Broad-angle Camera: 48MP 1/1.3-inch CMOS sensor with 82.1° DFOV and 24mm equivalent focal length.
Detailed Video: A video resolution of 3840 x 2160 @ 30 frames per second is supported by the wide and zoom cameras.
Night-scene Mode: Both the zoom and wide cameras have this feature.
More Stable Imagery: Image stabilisation algorithms successfully reduce shake in zoom camera telephoto footage.
Laser Rangefinder: An improved laser rangefinder that can measure up to 3,000 meters, which is 2.5 times farther than the H20 Series. Latitude, longitude, and altitude coordinates are shown in real time.
