DJI E-Port Development Kit
- Turns E-Port into several standard hardware ports.
Brand: DJI
Safe & Secure Checkout
DJI E-Port Development Kit
The E-Port Adapter Development Kit is a versatile tool for developers working with DJI drones, allowing the conversion of the E-Port on the aircraft into multiple standard hardware ports, such as XT30 Power Output, USB 2.0, and UART/PPS Signal Ports. This flexibility enables developers to connect and interface external hardware equipment, facilitating SDK development and debugging directly with DJI drones.
Main Features and Advantages
Multiple Standard Ports: Converts the aircraft’s E-Port to multiple hardware interfaces, providing easy access to power and data connections.
SDK Development Friendly: Streamlines SDK development by allowing integration with external hardware for various testing and debugging functions.
Port Compatibility: Designed to support a range of DJI drones, enhancing compatibility and adaptability for different payloads.
Usage Tips
Placement and Safety: To prevent potential short circuits, ensure the adapter board is properly placed and not in contact with the aircraft's arm.
Heat and Shielding: For integration into a payload, ensure the addition of a heat dissipation system and a metal shielding cover for operational safety and stability.
Monitoring and Power Limits: If any unusual conditions (sparks, smoke, smells) arise, disconnect power immediately. Be cautious with power outputs: when all XT30 ports are active, the combined output must stay below the drone’s max power capacity.
Included Components
E-Port Adapter Board x 1
Pin Header Protector x 1
E-Port Coaxial Cable (150 mm) x 1
XT30 to USB-C Power Cable (300 mm) x 1
XT30 to DC5.5 Power Cable (300 mm) x 1
Specifications
Adapter Board Dimensions: 55×40×9 mm
XT30 Power Output:
DJI Mavic 3E/3T: 12-17.6 V / 4 A
Matrice 30 Series: 19.2-26.1 V / 4 A
Matrice 300 RTK & Matrice 350 RTK: 24 V / 4 A
Additional XT30 Power Outputs:
12V / 2A
5V / 2A
Compatibility
DJI Matrice 350 RTK
DJI Matrice 300 RTK
DJI Matrice 30 and 30T
DJI Mavic 3E and 3T
