DJI SDR Transmission
Showing 1–3 of 3 products
DJI SDR Transmission Receiver
SDR Transmission, Stable & Anti-Interference · Strong Penetration, Extended Transmission Distance
£285.00
DJI SDR Transmission: Stable Wireless Video With Strong Penetration
DJI SDR Transmission uses Software-Defined Radio technology to prioritise signal stability, interference resistance, and penetration over maximum bitrate. That makes it suited to sets where walls, structures, and competing wireless kit break a conventional link, rather than to productions needing the highest possible image quality.
It supports both SDR and Wi-Fi transmission modes, so a feed can go to a dedicated receiver or straight to a phone or tablet when a temporary monitor is all that is needed.
Choose Your Configuration
| Product | Includes | Price |
|---|---|---|
| SDR Transmission Combo | Transmitter and receiver together | £519.00, restocking |
| SDR Transmission Transmitter | Transmitter only | £285.00, in stock |
| SDR Transmission Receiver | Receiver only | £285.00, in stock |
Buying the transmitter and receiver separately at £570 costs £51 more than the £519 combo. If the combo is restocking and you need kit now, the separates are available immediately. Individual receivers are also how you add monitoring positions to an existing setup.
SDR Transmission or DJI Transmission?
The two systems solve different problems, and the price gap is substantial.
Choose SDR Transmission for reliable monitoring in awkward environments, smaller crews, and budgets where £519 works and £1,979 does not. Penetration and stability are the priority.
Choose DJI Transmission for large sets needing maximum range, higher bitrate, ultra-low latency alongside cinema cameras, and integration with Master Wheels, Force Pro, and Ronin-series control.
| SDR Transmission | DJI Transmission | |
|---|---|---|
| Entry price | £519.00 | £1,979.00 |
| Max range | 3km (FCC), 2km (CE) | 6km / 20,000ft |
| Bitrate | Up to 20Mbps | Up to 50Mbps |
| Video | 1080p/60fps | 1080p/60fps |
| Receivers | Unlimited in Broadcast mode | Unlimited in Broadcast mode |
Range and Penetration
DJI rates SDR Transmission at up to 3km (10,000ft) under FCC, and 2km under CE, which is the figure that applies in the UK. Wi-Fi mode reaches around 200m, intended for temporary monitoring on a phone or tablet rather than distance work.
Penetration is where SDR earns its place. Where a conventional link degrades through walls, scaffolding, or vehicles, SDR holds a usable feed, which matters more than raw distance on most practical shoots.
Latency and Image Quality
Every specification below translates into something on set:
- Monitor at 1080p/60fps with up to 20Mbps bitrate, giving a feed clean enough to judge framing and general focus
- Work at 35ms latency excluding camera and display processing, or around 80ms end to end including it, which stays comfortable for directing and framing
- Switch to Wi-Fi mode at roughly 110ms latency when feeding a phone or tablet directly
- Hop frequencies automatically across 2.4GHz, 5.8GHz, and DFS bands, holding the link as the wireless environment changes
- Connect unlimited receivers in Broadcast mode, so several crew members monitor simultaneously from one transmitter
Two-Way Communication
The receiver supports one-to-one real-time voice communication with the transmitter through the 3.5mm stereo jack. A director or client can talk directly to the cinematographer without a separate comms system, which removes a whole category of kit from a small production.
Ports and Power
Transmitter
HDMI and SDI inputs supporting 1080p/60fps, plus USB-C handling gimbal communication, firmware updates, and power.
Receiver
HDMI and SDI outputs supporting 1080p/60fps video and audio, 3.5mm stereo jack for audio and calls, and USB-C for firmware updates and video output.
Both units weigh around 145g including antennas, with foldable antennas for flexible mounting and easy storage. Power draw is roughly 8.3W, and both run from NP-F batteries or USB-C chargers using the PD protocol.
Compatibility
SDR Transmission works with:
- DJI RS series gimbals, including the RS 4 Mini and RS 5, with USB-C gimbal communication
- Any camera with HDMI or SDI output at 1080p/60fps
- Smartphones and tablets over direct Wi-Fi, with no receiver required
- Production monitors via HDMI or SDI output from the receiver
Call us with your exact camera and gimbal and we will confirm compatibility before you order.
Why Buy DJI SDR Transmission From Drone Safe Store
Genuine UK Stock, Next Day Delivery
Transmitter and receiver in stock now, with free next working day delivery seven days a week on in-stock orders.
Honest Advice on Which System You Need
The gap between SDR and full DJI Transmission is £1,460. Our team will tell you plainly when the cheaper system does the job.
See It Working Before You Buy
Book time with the system at our Chichester showroom, the largest indoor DJI store in the UK.
A Genuine DJI Authorised Retailer
DJI Enterprise A Rank status and ISO 9001 certification, supplying genuine stock with a full 24-month warranty.
In-House Servicing
Our own engineers handle repairs and servicing in Chichester.
Flexible Payment Options
Klarna, Clearpay, and PayPal Credit at checkout, plus iwocaPay for limited companies.
Frequently Asked Questions
What is SDR and why does it matter?
Software-Defined Radio handles signal processing in software rather than fixed hardware, which allows better stability, interference resistance, and penetration through obstacles. On a practical set, that means a feed that holds up through walls and around competing wireless kit.
What is the difference between SDR Transmission and DJI Transmission?
SDR starts at £519 and prioritises stability and penetration at up to 20Mbps. DJI Transmission starts at £1,979 and delivers longer range, 50Mbps bitrate, and deeper integration with Master Wheels, Force Pro, and Ronin control systems.
How far will SDR Transmission reach?
Up to 3km under FCC and 2km under CE, which is the figure applicable in the UK. Wi-Fi mode reaches around 200m for temporary monitoring on a phone or tablet.
How many people can monitor at once?
Broadcast mode supports an unlimited number of receivers from a single transmitter. Additional receivers are £285 each.
Can I monitor on a phone without a receiver?
Yes. Wi-Fi mode transmits directly to smartphones and tablets, which is useful for quick, temporary monitoring positions without extra hardware.
Can the director talk to the operator through it?
Yes. The receiver supports one-to-one real-time voice communication with the transmitter via the 3.5mm stereo jack.
Does it come with a warranty?
Yes. All new, sealed DJI products from Drone Safe Store carry a full 24-month warranty.
